Topklean EL 10F is a multi-purpose electronic cleaner from Inventec Performance Chemicals, formulated for the removal of flux residues, non-reflowed solder pastes and uncured glues. Because it works at ambient temperature via manual spray or immersion cleaning, technicians can use this ready-to-use formulation straight from the container, with no dilution required.
Topklean EL 10F Features
- Ready-to-use formulation, requiring no dilution before use
- Colorless, clear liquid with a density of 0.830 ± 0.010 g/ml at 20°C
- Higher flashpoint than IPA (38°C / 100°F), supporting safer handling
- CMR, aromatic and halogen free
- No global warming potential
- No pH, making it suitable for use on sensitive metals and alloys
- Partially soluble in water, with low non-volatile residue (<0.01 g/100 ml)
- Suitable for manual spray or immersion cleaning, with optional ultrasonic assistance
With a low water content (<0.1% weight) and low aromatics content (<0.01% weight), Topklean EL 10F leaves minimal residue on cleaned surfaces. As a result, its ambient-temperature process and ready-to-use format make it straightforward to introduce into manual cleaning workflows, without additional heating or dilution equipment.
Topklean EL 10F Applications
- Removal of flux residues
- Removal of non-reflowed solder pastes
- Removal of uncured glues
- Manual spray cleaning
- Immersion cleaning
Technicians typically use Topklean EL 10F with immersion times of 1–5 minutes for cleaning and 1–2 minutes for rinsing at ambient temperature. In addition, they can pair it with optional ultrasonic assistance to enhance cleaning performance.
Product Specifications
| Attribute | Detail |
|---|---|
| Appearance | Colorless, clear |
| Density at 20°C | 0.830 ± 0.010 g/ml |
| Flash point | 38°C / 100°F |
| Evaporation rate (nBuAc=1) | 0.15 |
| Water solubility | Partially soluble |
| Water content | <0.1% weight |
| Aromatics content | <0.01% weight |
| Non-volatile residue | <0.01 g/100 ml |
| Viscosity at 25°C | 302 mm²/s |
| Vapor pressure at 20°C | 2.8 hPa |
| Boiling range | 150–170°C / 302–338°F |
Recommended Process Parameters
| Parameter | Detail |
|---|---|
| Temperature | Ambient |
| Concentration | 100% (ready-to-use) |
| Immersion time (cleaning) | 1–5 minutes |
| Immersion time (rinsing) | 1–2 minutes |
| Ultrasonic assistance | Optional |
Finally, full technical data for Topklean EL 10F is available in the product datasheet, and safety information is accessible via the MSDS finder.
Looking for a heavier residue-removal option? Additionally, explore Topklean MC 20D, or browse our full range of Precision Cleaning Chemicals for manual, spray and immersion cleaning solutions.
